Operating weight
Bucket capacity (m³)
Rated power

Utilities

Heavy infrastructure

Quarries & Aggregates
| Operating weight | 3300KG |
| Bucket capacity (m³) | 0.45m³ |
| Rated carrying-capacity | 950KG |
| Engine model | WP3.2G61E317 |
| Rated power | 45KW |
| Max. traction force | 29KN |
| Max. tearout force | bucket>20KN,boom>18.5KN |
| Max. Speed | 11.5km/h |
| Fuel tank | 82L |
| Overall length | 3405mm |
| Overall width | 1880mm |
| Overall heigth | 2000mm |
| wheelbase (front /rear) | 1072mm |
| Wheel track | 1370mm |
| Minimum ground clearance | 185mm |
| Maximum dumping height | 2390mm |
| Dumping distance | 585mm |
| Maximum height of bucket hinge point | 3060mm |
| Dumping angle | 45mm |
| Transverse passing radius (outside of bucket) | 2105mm |
| Minimum steering radius (outside of rear wheel) | 1210mm |
