| Standard bucket capacity | 2.1m³ |
| Rated load | 3500KG |
| Operating weight | 10940KG |
| Engine | L035HW2215A29E0 |
| Rated power | 105KW |
| Max Breakout force | 96KN |
| Max Tractive force | 100KN |
| Tire size | 20.5-25 |
| Fuel tank | 200L |
| Overall length | 7320mm |
| Overall width | 2520mm |
| Overall heigth | 3170mm |
| Wheelbase | 2850mm |
| Ground clearance | 370mm |
| Dumping angle | 45° |
| Dumping height | 2930mm |
| Turning radius at over bucket | 6065mm |
| Turning radius at inside of tires | 5250mm |
