Rated load
Operating weight
Rated power

Utilities

Heavy infrastructure

Quarries & Aggregates
| Standard bucket capacity | 0.8m³ |
| Rated load | 1600KG |
| Operating weight | 5250KG |
| Engine | YUNNEI 4EZ080-30CR |
| Rated power | 61.8KW |
| Max Breakout force | 47KN |
| Max Tractive force | 50KN |
| Tire size | 16/70-20 |
| Fuel tank | 90L |
| Overall length | 5765mm |
| Overall width | 2140mm |
| Overall heigth | 2925mm |
| Wheelbase | 2235mm |
| Ground clearance | 330mm |
| Dumping angle | 45° |
| Dumping height | 2455mm |
| Turning radius at over bucket | 5080mm |
| Turning radius at inside of tires | 4490mm |
