Rated Load (kg)
Standard Bucket Capacity (m³)
Operating Weight (kg)
Rated Power (kW)

Utilities

Heavy infrastructure

Quarries & Aggregates
Reliable: The BFM8 engine features high torque, strong power, high quality, and high product reliability. It also has a large market presence. Equipped with a unit pump and mechanical injectors, it has good fuel adaptability and stable engine performance. Adopting the SDLG wet axle, it has reasonable load distribution and strong load-bearing capacity. The wet braking system provides good braking effect, ensuring safety and reliability.
Energy saving: The load-sensing full-hydraulic steering system features a fast steering response speed and minimal energy loss. The dual-pump confluence hydraulic system reduces the power loss of the hydraulic system, achieving energy efficiency. Three levels of power modes are set for different working conditions. Customers can select according to the actual working conditions, achieving high efficiency and energy conservation. The radiators are arranged in a single parallel row, which provides good heat dissipation effects, saves energy, and produces low noise.
Comfortable: The automatic transmission can automatically switch gears according to the vehicle speed. It offers a comfortable operation experience and reduces labor intensity.
| Rated Load (kg) | 5800 |
| Length×Width×Height (mm) | 8370x3024x3450 |
| Wheel Base (mm) | 3400 |
| Max.Dumping Height (mm) | 3110 |
| Dumping Distance (mm) | 1190 |
| Steering Angel (°) | 38 |
| Emission Standard | GB 20891-2014(stage III) |
| Max.Tractive Force (kN) | 160 |
| Max.Breakout Force (kN) | 180 |
| Fuel Tank Capacity (L) | 300 |
| Standard Bucket Capacity (m³) | 3.5 |
| Operating Weight (kg) | 18000 |
| Rated Power (kW) | 162 |
| Engine Model | BFM8-22T3 |
